| Product Name | SAE AISI 1020 Carbon Steel Plate | |
| Standard | ASTM,AISI,DIN,EN,BS,GB,JIS | |
| Grade | ASTM/ASME: A36, A283, A285, A514, A516, A572, A1011/A1011M | |
GB: Q195, Q235/Q235B, Q255, Q275, Q345/Q345B, Q420, Q550, Q690 | ||
| JIS: SS400, G3131 SPHC, G3141 SPCC, G4051 S45C, G4051 S50C | ||
| AISI: 1018, 1020, 1045 / SAE: 1010, SAE 1020, SAE 1045 | ||
| Technique | Hot rolled / Cold rolled | |
| Type | Mild steel / Medium carbon steel / High carbon steel | |
| Surface | Coated | |
| Processing | Welding, Cutting, Bending, Decoiling | |
| Delivery time | 10-30 days subject to the clients' requirement and quantity | |
| Package | clients' requirement and Standard export sea-worthy packing | |
| MOQ | 1 ton | |
Available Size Range
| Dimension | Range |
| thickness | 0.5-300mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, etc. or customer's request |
| Length | 1000mm~6000mm, or as customer's request |
Chemical Composition
| AISI SAE 1020 Steel Chemical Composition (%) | ||||
| AISI | C | Mn | P (≤) | S (≤) |
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 |
Mechanical Properties
| Mechanical Properties | ||||
| Steel Grade | Yield Strength | Tensile Strength | Elongation % (Ø ≤40mm) | |
| Ø ≤16mm | 16mm ＜ Ø ≤60mm | |||
| Q195 | 195 N/mm2 | 185 N/mm2 | 315 to 430 N/mm2 | 33 |
1 MPa = 1 N/mm2; Ø = Wire Diameter or Thickness
Application
ASTM AISI SAE 1020 steel has many semi-finished products, such as square steel bars, flat steel bars, round steel bars, steel plates, which can be used to make truck, automotive and agricultural equipment parts such as axles, mechanical parts, cold head bolts, motor shafts, pump shafts, ratchet, light gear, gear drives, worm gear, spindle, seat bracket, crane-cable drum, motor-brake wheel, etc. And usually also made into steel channels, steel angles, I-beams and H-beams.
